Prime III RT UPS Rack/Tower Convertible (1KVAto 3KVA) New

The Prime III RT UPS is an ideal power protection solution for use in industries like finance, communications, insurance, medicine, and enterprises. It is a new generation Rackmount / Tower convertible series with up to 96 percent efficiency in ECO mode. The UPS is one of the most adaptable UPS available because of its form factor design and broad range of installation options.

Download Technical Specification Enquire Now

Description

The PowerHub Prime III RT UPS produces only pure sine waves in battery mode. As a result, the connected devices receive high-quality electrical input and continue to function normally even during a power loss.

Reliability: The Prime III RT UPS maximizes the availability of your IT systems with extended battery duration choices, hot-swappable batteries, internal bypass, and optional maintenance bypass.

More power: The Prime III RT UPS offers up to 10% more wattage than conventional UPS, allowing you to connect more devices.

Efficiency: With up to 90% efficiency rating in double conversion online mode means efficiency energy management and low heat dissipation for energy saving and improved reliability.

Reduce battery charging time: Batteries may now be charged up to 90% of their capacity in under 8 hours. Thanks to the built-in chargers of the UPS and the External Battery Pack (EBP).

Simple LCD interface: The simple LCD interface from Prime III RT UPS offers a graphical display that gathers all important UPS data in one place. Information and settings can be made using the panel buttons.

  • Wide Input Voltage Range: 110-300VAC permits erratic power conditions and minimizes battery transfer.

  • ECO Mode: Through the LCD display, the input voltage regulation range can be adjusted or updated in energy-saving mode.

  • Generator Compatible: Ensures that loads receive clean, uninterrupted power during a prolonged power outage.

  • Cold Start Function: Enables connected hardware to be started in an emergency when the UPS is not powered.

  • Intelligent Battery Management: Maximizes battery performance through intelligent precision temperature-compensated charging.

  • USB Port / Serial Port: Provides management of the UPS via USB/serial communication.

  • Power Conditioning: Provides protection for connected loads against surges, spikes, lightning, and other power disturbances.

  • Built-in Automatic Bypass: Guarantees uninterrupted power to the load even in the case of a catastrophic UPS failure.

  • Emergency Power Off (EPO): In an emergency, shuts off power to any connected devices right away.

  • Extended Runtime Models Available: Scales runtime from minutes to hours by adding external battery packs, meeting the demands of long duration applications.
  • Power Rating: 1000 to 3000VA
  • Power Factor: 1.0
  • Voltage: 220-240 Vac
  • Frequency: 50/60 Hz (auto sensing)
  • THDv < ≤3% Linear load, ≤5% Non linear load
  • Efficiency up to 94%
  • Configuration: Rack/Tower Convertible Design
  • IEC62040-1, IEC62040-2, and IEC62040-3 Compliance
  • Internal or External SNMP Card (Optional)
  • Relay Card (Optional)
  • External Environmental Probe (Optional)

Prime III RT 1KVA

Move your mouse over the chart to see the runtime at any load.
Configuration10%20%30%40%50%60%70%80%90%100%
UPS (Std)46 min26 min17 min12 min8 min6 min4 min4 min3 min3 min
UPS (Std) + 1 EBP184 min104 min70 min49 min38 min30 min25 min21 min18 min16 min
UPS (Std) + 2 EBPs346 min195 min130 min94 min72 min57 min48 min40 min34 min30 min
UPS (Std) + 3 EBPs520 min305 min201 min142 min110 min87 min73 min61 min52 min46 min
UPS (Std) + 4 EBPs682 min402 min280 min195 min148 min120 min100 min83 min72 min64 min

Prime III RT 2KVA

Move your mouse over the chart to see the runtime at any load.
Configuration10%20%30%40%50%60%70%80%90%100%
UPS (Std)45 min26 min17 min12 min8 min6 min4 min4 min3 min3 min
UPS (Std) + 1 EBP179 min104 min70 min49 min39 min30 min25 min21 min18 min16 min
UPS (Std) + 2 EBPs346 min195 min133 min94 min73 min57 min47 min40 min34 min31 min
UPS (Std) + 3 EBPs494 min305 min201 min142 min112 min87 min72 min61 min52 min47 min
UPS (Std) + 4 EBPs682 min402 min280 min195 min152 min120 min100 min83 min72 min64 min

Prime III RT 3KVA

Move your mouse over the chart to see the runtime at any load.
Configuration10%20%30%40%50%60%70%80%90%100%
UPS (Std)46 min27 min18 min12 min8 min6 min4 min4 min3 min3 min
UPS (Std) + 1 EBP184 min108 min72 min50 min39 min31 min25 min21 min18 min16 min
UPS (Std) + 2 EBPs346 min201 min136 min97 min73 min58 min48 min41 min35 min31 min
UPS (Std) + 3 EBPs520 min318 min207 min145 min112 min90 min73 min62 min53 min47 min
UPS (Std) + 4 EBPs682 min417 min292 min195 min152 min120 min102 min85 min73 min64 min

Runtime figures are typical battery backup times in minutes at the stated load. EBP = External Battery Pack.

Disclaimer: The runtime durations shown above are for reference only. Actual battery backup time may vary depending on the environment in which the UPS is installed, including ambient temperature, battery age and condition, and other site-specific factors.
